19 Inch Embedded Fully Enclosed Touch Screen Industrial All In One Machine
Industrial control all-in-one machine, including embedded industrial touch all-in-one machine, wall mounted industrial touch integrated machine and other styles. Independent research and development of the whole machine, industrial Android tablet computer, create a new interactive experience.
1. Subvert the tradition, break through the industry restrictions: face value and strength of the co-existence of fully enclosed embedded industrial control all-in-one machine.
2. Brand authority certification: high tech enterprises, standardized production enterprises.
3. Scene display: Super applicability, can adapt to more harsh environment, stable use.
4. Die casting private mold, all aluminum body: Die Casting fully closed fan less heat dissipation, rear cover all aluminum fin design.
5. Not only to upgrade, but also to win quality: high configuration, high technology, high enjoyment, give you a new experience.
6. Full closed integrated back cover, burst performance, strength attack: all aluminum alloy integrated back cover, strong hardness, pressure resistance, durable, embedded installation and fitting terminal equipment.
7. Play high-tech, immersive quiet experience: fully enclosed fanless dust-proof design, better and more stable heat dissipation performance.
8. Both the appearance value and the heat dissipation strength: the running speed is fast, the performance is stable, and the heat dissipation effect of the whole machine is improved several times.
9. Seamless design, consistent inside and outside: dust proof, splash proof, oil proof, break through environmental restrictions, more suitable for industrial automation equipment in harsh environment.
10. All aluminum alloy fuselage, solid as a rock: metal material, strong quality, thin between, create the beauty of both internal and external repair.
| Brand:LIQUISE Screen specifications: 15 inches Screen ratio: 4:3 Resolution: 1024x 768 Backlight type: LED Motherboard: J1800/J1900 industrial control motherboard | Memory: 2G/4G/8G (upgradeable) Interface: VGA x 1HDMIx 1USBx4L AN
x 1COM x 2 audio input/output x 1DC Power connector x 1 Network card: Built-in Gigabit network card Graphics: Integrated HD |
| Common system: win7/win10/Android Normal power: ≤40W Working temperature: -10C~+60C Environmental humidity: 20%~70% Product certification: CE, FCC, CCC Applicable industries: Industry, Commerce | Touch screen: Resistive/Capacitive Response time: 5ms Display brightness: 350cd/m2 Contrast ratio: 1000:1 Color depth: 16.7M CPU: Celeron dual-core 2.41GHz/quad-core 1.99GHz |
| Power supply: External power supply 12V Special structure: Fanless dustproof structure Aluminum alloy cooling back cover Can be installed and built-in: Wireless wifi, 4G, Bluetooth(optional) Viewable size: 304mm x 228mm Shell size: 378mm x 297mm | Bracket hole: 75mm x 75mm Appearance material: Metal cold rolled sheet Bracket: Wall Hanger / Die-casting desktop bracket (optional) |
| Capacitor size Shell width(mm) Shell heigh(mm) Thickness(mm) Screen width(mm) Screen heigh(mm) Screen Resolution (mm) Wall hole position (mm) Screen width:height | 8.4inches 236 190 51.5 170.4 127.8 800*600 100*100 4:3 | 10.4 inches 283 225.2 56.2 213.1 160.3 1024*768 100*100 4:3 | 12.1 inches 317 258 56.2 246 184.5 1024*768 100*100 4:3 | 15 inches 378 297 56.2 304 228 1024*768 100*100 4:3 | 17 inches 413 342 56.2 338.92 271.34 1280*1024 100*100 4:3 | 19 inches 454 375.5 62.7 377.3 302.1 1280*1024 100*100 4:3 | 22 inches 559 349.3 65.5 477.6 261.1 1920*1080 100*100 16:9 |
